Windows 10 Credential Guard and Cisco ISE Conflicts Using PEAP

If you have enabled credential guard in Windows 10 and have a network security mechanism like Cisco ISE or just plain Enterprise WPA2 - then you will run into some issues if you have set your authentication method to PEAP (EAP-MSCHAPv2).

Credential Guard is a powerful security mechanism against Man-in-the-Middle attacks that have become more common with the rise of the Cryptolocker ransomware.

The service enables virtualization-based security by using the Windows Hypervisor to support security services on the device.

Microsoft makes this available to all their customers running Windows 10 on supported devices, and it is fairly simple to implement.

NOTE (Updated 2026): Starting with Windows 11 22H2, Credential Guard is enabled by default on all eligible devices that meet hardware requirements. On Windows 11 Enterprise and Education editions, Credential Guard is enabled automatically during upgrade if the hardware supports it. This means the PEAP compatibility issue described in this post may now affect a much larger population of devices than when it was originally written.

But it turns out that enabling the service will prevent the authentication supplicant in Windows 10 from sending the user's credentials to the Cisco ISE RADIUS service (or ANY RADIUS server for that matter).

So if you have enabled Credential Guard in Windows 10 and have a network security mechanism like Cisco ISE or just plain Enterprise WPA2 - then you will run into issues if you have set your authentication method to PEAP (EAP-MSCHAPv2).

And you will notice a lot of entries in the Cisco ISE live authentications view, similar to this:

5440 Endpoint abandoned EAP session and started new

What to Do?

Unfortunately, a fix from either Cisco or Microsoft does not seem available at the time of writing this, so switching over to a certificate or smart-card based authentication is the only option short of disabling Credential Guard.

I recommend using certificate-based authentication with User certificates, which can be distributed either through Group Policy or via Microsoft Intune.

And it might never get "fixed" since Credential Guard was developed to secure against tools like Mimikatz, which basically does the same thing as PEAP authentication - namely passing the users hashed credentials.

Let's hope an alternative comes along in the future. As the PEAP option does provide some flexibility over using certificates, albeit being slower to authenticate. Though I doubt it as this is the price of added security. And PEAP is not as safe as some might think.

That's why I recommend using certificate-based authentication with User certificates, which can be distributed either through Group Policy or via Microsoft Intune, leveraging SCEP.

---

For Those Trying to Find This Info via Google

Below is a sample of the steps that occur in Cisco ISE when the client tries to connect and fails:

Steps
11001  Received RADIUS Access-Request
11017  RADIUS created a new session
15049  Evaluating Policy Group
15008  Evaluating Service Selection Policy
15048  Queried PIP
15048  Queried PIP
15048  Queried PIP
15048  Queried PIP
15004  Matched rule
15048  Queried PIP
15048  Queried PIP
15004  Matched rule
11507  Extracted EAP-Response/Identity
12500  Prepared EAP-Request proposing EAP-TLS with challenge
12625  Valid EAP-Key-Name attribute received
11006  Returned RADIUS Access-Challenge
11001  Received RADIUS Access-Request
11018  RADIUS is re-using an existing session
12301  Extracted EAP-Response/NAK requesting to use PEAP instead
12300  Prepared EAP-Request proposing PEAP with challenge
12625  Valid EAP-Key-Name attribute received
11006  Returned RADIUS Access-Challenge
11001  Received RADIUS Access-Request
11018  RADIUS is re-using an existing session
12302  Extracted EAP-Response containing PEAP challenge-response and accepting PEAP as negotiated
12318  Successfully negotiated PEAP version 0
12800  Extracted first TLS record; TLS handshake started
12805  Extracted TLS ClientHello message
12806  Prepared TLS ServerHello message
12807  Prepared TLS Certificate message
12810  Prepared TLS ServerDone message
12305  Prepared EAP-Request with another PEAP challenge
11006  Returned RADIUS Access-Challenge
11001  Received RADIUS Access-Request
11018  RADIUS is re-using an existing session
12304  Extracted EAP-Response containing PEAP challenge-response
12318  Successfully negotiated PEAP version 0
12812  Extracted TLS ClientKeyExchange message
12804  Extracted TLS Finished message
12801  Prepared TLS ChangeCipherSpec message
12802  Prepared TLS Finished message
12816  TLS handshake succeeded
12310  PEAP full handshake finished successfully
12305  Prepared EAP-Request with another PEAP challenge
11006  Returned RADIUS Access-Challenge
11001  Received RADIUS Access-Request
11018  RADIUS is re-using an existing session
12304  Extracted EAP-Response containing PEAP challenge-response
12313  PEAP inner method started
11521  Prepared EAP-Request/Identity for inner EAP method
12305  Prepared EAP-Request with another PEAP challenge
11006  Returned RADIUS Access-Challenge
11001  Received RADIUS Access-Request
11018  RADIUS is re-using an existing session
12304  Extracted EAP-Response containing PEAP challenge-response
11522  Extracted EAP-Response/Identity for inner EAP method
11806  Prepared EAP-Request for inner method proposing EAP-MSCHAP with challenge
12305  Prepared EAP-Request with another PEAP challenge
11006  Returned RADIUS Access-Challenge (Step latency="1001 ms)
5440   Endpoint abandoned EAP session and started new

Note that this is not a bug! It will affect any authentication using PEAP as this is the design of Credential Guard.

Conclusion

Please note that this is not a bug! It will affect any authentication using PEAP as this is the design of Credential Guard - so you might want to consider this problem if you have other services that rely on PEAP, and experience issues after enabling Credential Guard.

Read more about this new security mechanism here: https://docs.microsoft.com/en-us/windows/access-protection/credential-guard/credential-guard
